Fused quartz Ball lens

Fused quartz Ball lens
  • Ball lens is used to improve the signal coupling between optical fiber, transmitter and detector and improve the signal quality. It can also be used in endoscopy, bar code scanning, pre-processing materials of aspheric lens, sensors, etc. The rear focal length of the spherical lens is short, which can greatly reduce the distance from the spherical lens to the optical fiber.
Technical parameters
Items Parameters
Material UV fused quartz (JGS1, Corning 7980), infrared fused quartz (jgs3, Corning 7978)
Radius of curvature ± 1mm - ± 50000mm ± 1%
Diameter 3mm-40mm ± 0.1mm
Center thickness tolerance ± 0.05mm (we can process to ± 0.01mm with high precision)
Center deviation 3′(we can process to 30 ″with high precision)
Surface accuracy λ/ 8 (high precision, we can process to 1 / 10λ)
Surface quality 40/20 (we can process to 10-5 with high precision)
Effective caliber ≥92%
spectral curve

In addition, we have thousands of stock of K9 plano convex lens, biconvex lens, plano concave lens, biconvex lens, meniscus lens and so on. The price is preferential and the quality is excellent, which can meet your demand for a small order.
